| Model Number: | LYABG |
| MOQ: | 1 unit |
| Price: | USD 150,000-350,000 per unit |
| Payment Terms: | D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 1 unit per month |
Precision Meets Innovation in Biopharmaceutical Production
The Ampoule Filling and Sealing Machine by Suzhou Lingyao Pharmaceutical Equipment Co., Ltd. is engineered to meet the rigorous demands of monoclonal antibody (mAb) production. Designed for 1-20ml ampoules, this fully automated system integrates cutting-edge servo-driven technology and ISO 5-class air filtration to ensure sterility, speed, and unmatched precision—perfect for high-value biologics requiring stringent quality control.
Why Choose This Ampoule Filling Line?
✅ Ultra-Precise Dosing: Advanced ceramic piston pumps deliver filling accuracy within ±0.5% deviation, critical for dose-sensitive mAb therapies.
✅ GMP/FDA Compliance: Constructed with 316L stainless steel and equipped with real-time monitoring (temperature, pressure, particulate levels), it adheres to global pharmaceutical standards[[1].
✅ High-Speed Output: Achieve up to 24,000 ampoules/hour with seamless integration into cleanroom environments, minimizing production bottlenecks.
✅ Zero-Contamination Design: Features automatic CIP/SIP functions, leak-proof sealing, and laminar airflow to protect sensitive biologics from oxidation or microbial ingress.
Machine Spec:
| technical parameters | ||||
| product model | LYQCL120+LYASMR 620/43+LYAGF8 |
|||
| size range | 1-10ml national standard ampoules | |||
| Output(1-2ml) | 12000-16000pcs/h | |||
| Output(5-10ml) | 8000-12000pcs/h | |||
| Clarity | ＞99% | |||
| Breakage rate | ≤1%(whole line) | |||
| Filling Precision | ±0.5%(according to pharmacopoeia standard) | |||
| Water Consumption and Pressure | 0.2-0.4Mpa / 0.6-1.0m³/h | |||
| Cleaning CA Consumption and Pressure | 0.3-0.6Mpa / 35-80m³/h 0.3-1.0Mpa / 35-80m³/h | |||
| Sealed gas | Gas(liquefied gas)+oxygen, oxyhydrogen generation gas, natural gas | |||
| Oxygen consumption | 0.2-0.3Mpa,1.2-1.5m³/h | |||
| Gas consumption | 0.1-0.3Mpa,1.5-2.5m³/h | |||
| Exhaust volume | 3500-4100m³/h | |||
| Net weight | 7800(kg) | |||
| Total power | around 72kw 380V 50HZ | |||
| Outline size | around 9940x2260x2445mm | |||
Ideal for:
Technical Highlights:
Global Trust, Local Support
Backed by Suzhou Lingyao’s 12-year expertise in pharmaceutical machinery, this ampoule filling line has been deployed across 15+ countries, from vaccine hubs in the Middle East to biotech innovators in Europe. Customizable configurations and 24/7 remote diagnostics ensure uninterrupted production for your mission-critical biologics.
